Mutation Testing

Letting a mutant army test our tests

Created by Bobby Lough
http://www.bobbylough.com

Our project has great code coverage...

our unit tests are awesome!!!

The End

Protecting our projects are

  • quality engineers
  • unit tests
  • integration tests
  • smoke tests
  • code coverage reports
  • static code analysis tools
  • and lots of awesome sauce

Myth #1

The tests pass so the project must be defect free

Myth #2

Line coverage and conditional code coverage means the tests are good

Line Coverage != Good Tests

public static int sum(int x, int y) {
	return x + y;
}
@Test
public void testSum(
	int result = Code.sum(2,2);
)

100% line coverage but no asserts

Passing test with Asserts

but does that mean there are no bugs?

public static int sum(int x, int y) {
	return x * y;
}
@Test
public void testSum(
	int result = Code.sum(2,2);
	assertEquals(4, result);
)

Unit tests, aka Sentinels, protect our projects from bugs

But who protects our projects from our tests?

Send in the mutants!!!

What is a Mutant?

A mutation is a single syntactic change to the code. Each mutant is different from the original by a single mutation.

These small changes can have big results; such as changing an operator from addition to subtraction.

Then our unit tests execute against the mutant code and in theory our tests should fail because the code is wrong.

Mutation Outcome #1

The test fails

The mutant is caught/killed. Hooray!!!

Mutation Outcome #2

Mutation Outcome #3+

The test times out because the mutant caused an infinite loop

The test runs out of memory.

The mutant was dead on arrival and JVM just didn't like it.

mutant survival score

number of mutants killed / total number of mutants

What are some of the different types of Mutants?

Mutator: Conditionals Boundary

Original Mutant
> >=
< <=
>= >
<= <

Mutator: Negate Conditionals

Original Mutant
== !=
!= ==
<= >
>= <

Mutator: Math

Original Mutant
+ -
- +
* /
/ *
% *

Mutator: Remove Conditionals

if (condition1 == condition2) {
	doSomething();
}

changes to:

if (true) {
	doSomething();
}

Mutator: Return Value

always return true

always return false

always return null

always return 0

always return 3.145

Other Mutators:

  • Void method call removal (aka line removal)
  • Inline constant changes
  • Constructor manipulation
  • etc

Lots of mutants


public int additionOrSubtraction(boolean isAddition, int x, int y) {
	if (isAddition) { //mutant: replace isAddition with !isAddition
		return x + y; //mutants: replace + with -,*,/,%
	} else {
		return x - y; //mutants: replace - with +,*,/,%
	}
}

Too many mutants

Mutant testing is CPU and memory intensive. There are really too many possible mutants to run against your unit tests so the mutation engine chooses likely mutants.

PIT - Java Mutation Testing

"PIT is a state of the art mutation testing system, providing gold standard test coverage for Java and the jvm. It's fast, scalable and integrates with modern test and build tooling."

PIT:

  • highly configurable
  • built in reporting
  • works with Maven and ANT
  • Eclipse plugin available (PitClipse)
  • IntelliJ plugin available
  • Sonar integration
  • compatible with mocking frameworks
  • open source
  • and more

PIT reporting:

PitClipse results:

Configuring PIT Build in maven pom - Part 1





         org.pitest
         pitest-maven
         1.1.5


                  com.bobbylough.MutationTestingDemo.*


                  com.bobbylough.MutationTestingDemo.*





Configuring PIT Build in maven pom - Part 2





         org.pitest
         pitest-maven
         1.1.5



                  report







Running PIT

> mvn clean install org.pitest:pitest-maven:mutationCoverage

Realistic results from mutation testing

  • some mutants will survive
    • example: surviving mutant removed logger statement
  • some mutants are ridiculous
  • focus on killing the best mutants
    • my favorite: removing lines of code in a model builder

Summary

  • Unit tests and code coverage provide a false sense of security
  • Mutation Testing tests your tests. Watches the Watchers.
  • PIT makes mutation testing easy

Resources

Questions?
